NFPA 52-2019: Vehicular Natural Gas Fuel Systems Code

Big NFPA 52-2019 tanker truck with natural gas fuel systems.

The 2019 edition of NFPA 52: Vehicular Natural Gas Fuel Systems Code has been released.

The Use of Natural Gas in Motor Vehicles

According to the U.S. Department of Energy, natural gas fuels more than 160,000 vehicles in the United States and 15 million worldwide. The distinct advantages of using natural gas make it clear why so many drivers make this choice. In addition to reducing greenhouse gas emissions, natural gas fueled vehicles lead to a lower annual fuel cost and high engine performance.

There are three different types of vehicular natural gas fuel systems:

  • Dedicated – operates using only natural gas.
  • Bi-fuel – allows for interchangeability between two separate fuel systems of natural gas and gasoline.
  • Dual fuel – enables the use of both natural gas and gasoline simultaneously, but is generally restricted to only heavy-duty vehicles.

Additionally, natural gas can be available in two different forms. Compressed natural gas (CNG) remains in a gaseous state as it is compressed to more than 3,600 pounds per square inch. CNG is most commonly used to power vehicles like buses and trucks due to the need for larger fuel tanks. Liquefied natural gas (LNG), on the other hand, is ideal for longer distances where refueling would be more scarce. In this form, natural gas has been compressed and cooled to about -260 degrees Fahrenheit, which converts the gas to a liquid state and reduces its volume. Once the gas is ready to be used, LNG can be converted back into its gaseous state for distribution.

Fueling up with CNG with NFPA 52-2019 gas nozzle.

The 2019 Vehicular Natural Gas Fuel Systems Code

Despite the advantages of natural gas fuel systems, there are hazards with its use. Natural gas is a non-toxic substance, but high concentrations in confined spaces can cause health risks, like suffocation, and fire hazards as it is a combustible substance. NFPA 52-2019: Vehicular Natural Gas Fuel Systems Code describes the design, installation, operation, and maintenance of compressed natural gas (CNG) and liquefied natural gas (LNG) engine fuel systems on vehicles of all type, fueling vehicle (dispensing) systems and facilities, and associated storage.

The purpose of NFPA 52-2019 is to provide updated safety guidelines against fire and explosion hazards associated with CNG and LNG engine fuel systems, refueling stations and associated storage. The 2019 edition of the vehicular natural gas fuel systems code specifies the following subsystems or components associated with storage and dispensing of CNG and LNG as an engine fuel in fleet and public dispensing operations:

  1. Pressure relief devices, including pressure relief valves
  2. Pressure gauges
  3. Pressure regulators
  4. Valves
  5. Hose and hose connections
  6. Vehicle fueling connections
  7. Engine fuel systems
  8. Electrical equipment related to storage or dispensing systems
  9. Gas detection equipment and alarms
  10. Fire protection and suppression equipment
  11. Vehicle fueling appliances (VFAs)
  12. Residential fueling appliances (RFAs)

Additional guidelines regarding the total volume of contained gas for indoor units, the installation of piping or tubing that is to pass through the floor of a vehicle, and the identification of personnel engaged in the inspection, maintenance, repair, replacement, removal and testing of natural gas fuel systems are included in NFPA 52-2019 as revisions to the previous edition of the code.
