ANSI/IES LM-80-20: Measuring LED Luminous Flux and Color Maintenance

Many lights around LED are depleted and need to be tested to ANSI/IES LM-80-20 for luminous flux and color maintenance

An American National Standard, ANSI/IES LM-80-20: Approved Method: Measuring Luminous Flux And Color Maintenance Of LED Packages, Arrays, And Modules, is used to measure the light emitted by LEDs.

The Need to Measure LED Light

Comprehending the emission spectrum from light-emitting diodes (LEDs) is essential.

LEDs, like many other great inventions, were discovered by accident. In 1961, Robert Biard and Gary Pittman, while working on a laser diode, invented an infrared LED. Unfortunately, since this light was invisible to the human eye, it did not have any practical application. However, around this same time, experiments with arsenide phosphide as a semiconductor led to the creation of LEDs with practical use.

In the 1990s, the U.S. Department of Energy encouraged the development of white LED technology to provide commercial spaces with cost-efficient solutions. This burgeoned the use of the highly efficient LEDs we see today.

In fact, as discussed in ANSI/IES LM-80-20, LEDs typically exhibit very long operational life characteristics and, depending on drive current and use conditions, can be in use for 50,000 hours or longer. Unfortunately, this extreme efficiency comes with a drawback, since the light output of LEDs decreases over time. However, unlike incandescent lightbulbs, LEDs do not suddenly—and permanently—fail. In result, an LED product with declining output might be at risk to fall outside the product’s specification, required codes, standard practices, or regulations.

LED streetlights under sunset are depleted and need to be tested and measured to ANSI/IES LM-80-20

The ANSI/IES LM-80-20 Standard

To help confront this issue, the ANSI/IES LM-80-20 standard provides a method for users to measure the luminosity of LED lights. Specifically, its methods are used to measure luminous flux and color maintenance for LED packages, arrays, and modules. The standard covers luminous, radiant, or photon flux maintenance and color maintenance, including changes in chromaticity coordinates, peak wavelength, or centroid wavelength versus time.

In addition to the procedures themselves, ANSI/IES LM-80-20 outlines physical, environmental, and electrical conditions and considerations when preparing a test report. It also details case temperature monitoring and device under test (DUT) sample selection in its annexes.

Since this standardized method facilitates the measurement of maintenance characteristics under controlled conditions, results from different laboratories can be compared directly with one another.

ANSI/IES LM-80-20: Approved Method: Measuring Luminous Flux And Color Maintenance Of LED Packages, Arrays, And Modules is available on the ANSI Webstore.
